Microsoft supports a failover cluster solution only if all the hardware components are marked as “Certified for Windows Server 2008 R2.” In addition, the complete configuration (servers, network, and storage) must pass all tests in the Validate a Configuration wizard, which is included in the Failover Cluster Manager snap-in.

Note that this policy differs from the support policy for server clusters in Windows Server 2003, which required the entire cluster solution to be listed in the Windows Server Catalog under Cluster Solutions.

Cluster validation is intended to catch hardware or configuration problems before the cluster goes into production. Cluster validation helps to ensure that the solution you are about to deploy is truly dependable. Cluster validation can also be performed on configured failover clusters as a diagnostic tool.

Step by Step Guide

• Run the cluster validation wizard for a failover cluster

• If the cluster does not yet exist, choose the servers that you want to include in the cluster, and make sure you have installed the failover cluster feature on those servers. To install the feature, on a server running Windows Server 2008 or Windows Server 2008 R2, click Start, click Administrative Tools, click Server Manager, and under Features Summary, click Add Features. Use the Add Features wizard to add the Failover Clustering feature.

• If the cluster already exists, make sure that you know the name of the cluster or a node in the cluster

• For a planned cluster with all hardware connected: Run all tests.

• For a planned cluster with parts of the hardware connected: Run System Configuration tests, Inventory tests, and tests that apply to the hardware that is connected (that is, Network tests if the network is connected or Storage tests if the storage is connected).

• For a cluster to which you plan to add a server: Run all tests. Before you run them, be sure to connect the networks and storage for all servers that you plan to have in the cluster.

• For troubleshooting an existing cluster: If you are troubleshooting an existing cluster, you might run all tests, although you could run only the tests that relate to the apparent issue.

• In the failover cluster snap-in, in the console tree, make sure Failover Cluster Management is selected and then, under Management, click Validate a Configuration.

• Follow the instructions in the wizard to specify the servers and the tests, and run the tests.

• Note that when you run the cluster validation wizard on unclustered servers, you must enter the names of all the servers you want to test, not just one.

• The Summary page appears after the tests run.

• While still on the Summary page, click View Reportto view the test results.To view the results of the tests after you close the wizard, see SystemRoot\Cluster\Reports\Validation Report date and time.html where SystemRoot is the folder in which the operating system is installed (for example, C:\Windows)

Error Chart

Configuring the Quorum in a Failover Cluster

In simple terms, the quorum for a cluster is the number of elements that must be online for that cluster to continue running. In effect, each element can cast one “vote” to determine whether the cluster continues running. The voting elements are nodes or, in some cases, a disk witness or file share witness. Each voting element (with the exception of a file share witness) contains a copy of the cluster configuration, and the Cluster service works to keep all copies synchronized at all times

Note that the full function of a cluster depends not just on quorum, but on the capacity of each node to support the services and applications that fail over to that node. For example, a cluster that has five nodes could still have quorum after two nodes fail, but each remaining cluster node would continue serving clients only if it had enough capacity to support the services and applications that failed over to it.

Why Quorum is necessary

When network problems occur, they can interfere with communication between cluster nodes. A small set of nodes might be able to communicate together across a functioning part of a network, but might not be able to communicate with a different set of nodes in another part of the network. This can cause serious issues. In this “split” situation, at least one of the sets of nodes must stop running as a cluster.

To prevent the issues that are caused by a split in the cluster, the cluster software requires that any set of nodes running as a cluster must use a voting algorithm to determine whether, at a given time, that set has quorum. Because a given cluster has a specific set of nodes and a specific quorum configuration, the cluster will know how many “votes” constitutes a majority (that is, a quorum). If the number drops below the majority, the cluster stops running. Nodes will still listen for the presence of other nodes, in case another node appears again on the network, but the nodes will not begin to function as a cluster until the quorum exists again.

For example, in a five node cluster that is using a node majority, consider what happens if nodes 1, 2, and 3 can communicate with each other but not with nodes 4 and 5. Nodes 1, 2, and 3 constitute a majority, and they continue running as a cluster. Nodes 4 and 5 are a minority and stop running as a cluster, which prevents the problems of a “split” situation. If node 3 loses communication with other nodes, all nodes stop running as a cluster. However, all functioning nodes will continue to listen for communication, so that when the network begins working again, the cluster can form and begin to run.

Overview of the Quorum Nodes

There have been significant improvements to the quorum model in Windows Server 2008. In Windows Server 2003, almost all server clusters used a disk in cluster storage (the “quorum resource”) as the quorum. If a node could communicate with the specified disk, the node could function as a part of a cluster, and otherwise it could not. This made the quorum resource a potential single point of failure. In Windows Server 2008, a majority of ‘votes’ is what determines whether a cluster achieves quorum. Nodes can vote, and where appropriate, either a disk in cluster storage (called a “disk witness”) or a file share (called a “file share witness”) can vote. There is also a quorum mode called No Majority: Disk Only which functions like the disk-based quorum in Windows Server 2003. Aside from that mode, there is no single point of failure with the quorum modes, since what matters is the number of votes, not whether a particular element is available to vote.

This new quorum model is flexible and you can choose the mode best suited to your cluster.

Important: In most situations, it is best to use the quorum mode selected by the cluster software. If you run the quorum configuration wizard, the quorum mode that the wizard lists as “recommended” is the quorum mode chosen by the cluster software. We only recommend changing the quorum configuration if you have determined that the change is appropriate for your cluster.

There are four quorum modes:

• Node Majority: Each node that is available and in communication can vote. The cluster functions only with a majority of the votes, that is, more than half.
• Node and Disk Majority: Each node plus a designated disk in the cluster storage (the “disk witness”) can vote, whenever they are available and in communication. The cluster functions only with a majority of the votes, that is, more than half.
• Node and File Share Majority: Each node plus a designated file share created by the administrator (the “file share witness”) can vote, whenever they are available and in communication. The cluster functions only with a majority of the votes, that is, more than half.
• No Majority: Disk Only: The cluster has quorum if one node is available and in communication with a specific disk in the cluster storage.

Choosing the Quorum Mode for a particular cluster
